Name: Hand Lifted Gasoline Fire Monitor with High Lift and Large Flow Rate Water Pump RZJBG6.0/1.0
Brand: SHRAISE
SKU: 1
Availability: InStock
Rating: 5 (1 reviews)

Features

Heavy Duty Engine - Rugged 4-cycle industrial diesel delivers reliable power and fast response to load changes.

Alternator - Several alternator sizes offer selectable motor starting capability with low reactance 2/3 pitch windings, low waveform distortion with non-linear loads and fault clearing short-circuit capability.

Control system - The HGM6110Nelectronic control is standard equipment and provides total generator set system integration including automatic remote starting/stopping, precise frequency and voltage regulation, alarm and status message display, output metering, auto-shutdown at fault detection.

Cooling system - Standard cooling package provides reliable running at up to 50 °C (122 °F)

Low noise Enclosures - humanized design, the overall design of the chassis is compact and small, which has the role of reducing noise and protecting the generator set. 2MM steel box, rain proof, strong, surface resistance to ultraviolet light, rain, wear, not easy to fade and other advantages, bolts use rust, corrosion resistant stainless steel bolts; Reinforced mechanical door lock, long service life; Internal use of flame retardant muffler sponge, effectively reduce noise, more friendly to the environment. The interior is equipped with a top operating light for easy operation at night.

Fuel tank - Independent bottom for easy disassembly and maintenance. With wavy baffle, suitable for cutting. With lock refueling port, convenient refueling, anti-theft. Standard mechanical fuel gauge, can be customized electronic fuel gauge, you can check the oil level in the display. The use of oxidation resistance, high temperature resistance, high pressure special high pressure tubing, long service life. Anti-flatulence special fuel tank cap, safe to use.

Innovative Design & Prototype Testing - are key components of RAISE POWER's success in "increasing power by design." But it doesn't stop there. Fully committed to component testing, reliability testing, environmental testing, structural and life testing, as well as testing applicable to CSA, NEMA, EGSA and other standards, gives you confidence when choosing a SHRAISE generator set that these systems will deliver superior performance.

Warranty & Service - Backed by a comprehensive warranty and worldwide distributor and dealer network.

Specifications

Model	RZJBQ6.0/10
Engine model	RZ192FD
Startup method	Hand/Electric integrated
Speed	3800 ± 50r/min
Water diversion method	vacuum pump
Rated pressure	0.6MPa
Maximum working pressure	0.85MPa
Condition 1	Suction depth of 3 meters, flow rate: 10L/s
Condition 2	Suction depth of 7 meters, flow rate: 5L/s
Range	35-40m
Water pump type	single-stage centrifugal pump
Manufacturing standard	GB 6245-2006
Fuel tank capacity	6L
Weight	70kg
Packaging Size	630 * 630 * 1600mm
Warranty	1 year

1. Product Introduction

As a portable and high-efficiency fire-fighting equipment, the hand-carried mobile fire monitor plays an irreplaceable role in emergency fire fighting scenarios such as urban auxiliary fire protection, rural fire control, construction sites, forests and grasslands. Different from fixed fire monitors and electric fire-fighting equipment, it takes diesel engine as the core power source, combines the advantages of portability and strong power, and effectively makes up for the defects of insufficient fire-fighting power in remote areas, difficult access of large fire-fighting vehicles and limited power supply. This article will detail the core functions and unique advantages of this fire-fighting equipment, helping you fully understand its application value in fire safety work.

The hand-carried mobile fire monitor integrates power supply, water suction, pressure boosting and jetting, realizing an integrated fire-fighting operation mode that does not rely on external power and fixed water sources, and its core functions cover multiple links of emergency fire fighting, with strong practicality and operability.

First of all, it has efficient water suction and pressure boosting function. Equipped with a high-power diesel engine and a matching high-pressure water pump, the equipment can quickly suck water from natural water sources such as rivers, lakes, ponds and wells, as well as temporary water storage facilities such as water tanks and water bags, without the need for pre-installed water supply pipelines. The diesel engine provides stable and strong power, enabling the water pump to quickly build up high pressure, and the water outlet pressure can reach 0.8-1.2 MPa, which effectively solves the problem of insufficient water pressure in remote areas and ensures the fire-extinguishing effect. At the same time, the water suction range is wide, and it can normally suck water even when the water level is low, with strong adaptability to water sources.

Conclusion

The hand-carried mobile fire monitor, with its integrated functions of water suction, pressure boosting, jetting and independent power supply, and the unique advantages of portability, strong adaptability, high power and low cost, has become an important emergency fire-fighting equipment in various scenarios. It effectively makes up for the deficiencies of the existing fire-fighting system, solves the fire-fighting problems in remote areas and complex terrain, and provides a strong guarantee for people's life and property safety. Whether it is urban auxiliary fire protection, rural fire control, or forest and grassland fire prevention, this equipment can play an important role, and it is worthy of popularization and application in a wider range.
